- (1). [ Advanced H.265+ High Efficiency Video Compression ] __ ZOSI self-developed H.265+ video coding technology extract features that focus on characteristics of the surveillance scenes for larger storage space and better image quality. H.265+ can further improve compression ratio on the basis of H.265 standard and save about 80% storage compared with H.264, and thus effectively saving storage resources and provides an excellent and smooth viewing experience.
- (2). [ 2MP Extendable System Overview ] __ Exclusive H.265+ 16 Channel 1080N DVR Recorder paired with 8 weatherproof 1080p bullet dome cameras with 80ft night vision and 90°view angle(It allows you to add 8 more cameras). 60FT BNC+DC CCTV cabling provides both video and power to your cameras,more stable and reliable than wireless security system.(No Hard Drive Included)
- (3). [ Local or Remote Access, Playback Anytime & Anywhere ] __ View and control your security system locally by connecting the system to a monitor without internet, or via free ZOSI Client software on Windows or Mac, or via iOS & Android APP (ZOSI Smart ) on mobile devices remotely.You can also playback significant evidence or funny videos records by searching different days, hours or minutes.
- (4). [ Advance Motion Detection & Alert Push ] __ You can customize motion detection area in each camera to minimize false alerts from moving branches or animals,and block out selected areas to grant privacy in situations, people can not view of certain areas or activities. Instant notifications and email alerts with screenshot will be pushed to your phone directly as long as the cameras detect moving objects.
- (5). [ Customize Each Camera with Different Record Modes ] __Our ZOSI DVR offers 4 kinds recording modes to meet your needs: Record footage continuously; Record during scheduled times; Only record when detect motion; Recycle record. You can customize each camera with different recording modes, and download the recording files for the USB backup.
Product Description
This wired camera system can work without Internet Connection, but if you need to view remotely, then you need to connect the DVR to internet.
| | | |
Customizable Motion Detection Area of Camera
- Customize the motion detection area in each camera, reducing the number of false alarms, to save your time and allows you to stay connected to all the unexpected movements.
- In other words ,you can block out select areas on each screen, this is to grant privacy in situations, people can not view of certain areas or activities.
| Local and Remote Access in Multiple Devices
- Local Access: Connect the system to a monitor or TV via the HDMI cable or VGA cable;
- Remote Access: (Also need to connect the system to internet) Easy to get live streaming or playback videos via ZOSI App on iOS & Android devices, through ZOSI Client software on Windows or Mac,or via major browsers.
| Customize Each Camera with Different Record Modes
- ZOSI DVR offers 4 kinds recording modes to meet your needs: Record footage continuously; Record during scheduled times; Only record when detect motion; Recycle record.
- You can customize each camera with different recording modes, which allows you to save space on the hard drive, and you can download the recording files for the USB backup.
|
Package Contents
- 1 x 2MP 16CH 1080N Hybrid DVR
- 8 x 1080P HD Cameras
- 8 x 60FT DC+BNC Extension Cable for Cameras
- 8 x Mounting Screw Bag
- 3 x Power Adapter
- 2 x 1 to 4 Power Splitter cable
- 1 x Mouse
- 1 x User Manual
- This item does not come with hard drive.
- HDD Compatible with our DVR: Internal SATA 3.5" Consumer Electronics HDD.
16CH H.265+ 1080N DVR Specifications
| Operating System | Embedded LINUX OS |
| Compression Format | H.265+ |
| Video Input | 16 Channel |
| Video Output | 1CH HDMI+1CH VGA+1CH CVBS |
| Audio Input | 2H RCA |
| Audio Output | 1CH RCA |
| Trigger Event | Recording / PTZ / Tour / Alarm / Video Push / Email / Spot / Buzzer / Screen Tips |
| Internal Hard drive | 1 SATA Port(Up to 6TB) |
| Recording Modes | Manual / Motion / Schedule / Recycle |
| Ethernet | RJ-45 Port |
| USB Interface | 3 x USB2.0 |
| Maximum User Access | 10 Users |
| Remote Operation(3G/4G/WiFi) | Via http using IE & iPhone / iPad / Android / PC Client |
| PTZ Control | 1 Port RS485 for PTZ control |
| Power Supply | DC12V/3A |
| Operating Environment | ﹣10℃~ +55℃ (10%~90%RH) |
